Cheet sheat about Syslog based on RFC 5424
This is a draft cheat sheet. It is a work in progress and is not finished yet.
Protocol Information
A standard for message logging that allows applications and systems to send log messages to a centralized location for storage, analysis, and monitoring. Syslog uses UDP port 514! |
|
Syslog Message Format
seq no: timestamp: %facility-severity-MNEMONIC: description |
This is the the standard format for syslog messages, often used in Cisco devices
Breakdown of the Syslog message format
seq no |
represents the sequence number |
timestamp |
the date and time of the event |
facility |
represents what the log message is referring to |
severity |
severity code in the range 0 to 7 |
MNEMONIC |
short code for the message |
description |
brief description of the event |
Syslog Severity Levels
Severity |
Description |
Numerical code |
Emergency |
System is unusable |
0 |
Alert |
Action must be taken immediately |
1 |
Critical |
Critical conditions |
2 |
Error |
Error conditions |
3 |
Warning |
Warning conditions |
4 |
Notice |
Normal but significant condition |
5 |
Informational |
Informational messages |
6 |
Debug |
Debug-level messages |
7 |
Example of message generated by a Cisco router
*Mar 28 12:12:12.312: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet0/1, changed state to down
|
References and Further reading
|
|
Syslog Message Facilities
Numerical code |
Facility |
0 |
kernel messages |
1 |
user-level messages |
2 |
mail system |
3 |
system daemons |
4 |
security/authorization messages |
5 |
messages generated internally by syslogd |
6 |
line printer subsystem |
7 |
network news subsystem |
8 |
UUCP subsystem |
9 |
clock daemon |
10 |
security/authorization messages |
11 |
FTP daemon |
12 |
NTP subsystem |
13 |
log audit |
14 |
log alert |
15 |
clock daemon (note 2) |
16 |
local use 0 (local0) |
17 |
local use 1 (local1) |
18 |
local use 2 (local2) |
19 |
local use 3 (local3) |
20 |
local use 4 (local4) |
21 |
local use 5 (local5) |
22 |
local use 6 (local6) |
23 |
local use 7 (local7) |
Calculation of Priority
Priority = Facility 8 + Severity* |
For example, a kernel message (Facility=0) with a Severity of Emergency (Severity=0) would have a Priority value of 0.
|
